品牌：美国DAKOTA 型号：/FX81-DL 加工定制：否 类型：超声波 测量范围：0.630 - 2,440mm 分辨率：0.001mm 尺寸：216.0 x 165.0 x 70.0 mm 重量：2.04 kg 美国Dakota超声波探伤仪FX80-DL/FX81-DL （DFX-8）
Dakota FX80台式探伤仪系列将*先进的探伤技术与先进的材料厚度功能相结合。
简介
这些测量仪专为实验室使用而设计，是您满足所有探伤需求所需的工具。
Dakota FX80台式超声波探伤仪有两种型号：Dakota FX 80-DL台式探伤仪和Dakota FX81-DL台式探伤仪。
时间校正增益（TCG）功能自动补偿材料的声音衰减，进一步提高了仪表的性能。
在Dakota FX80探伤仪的网格批处理中，用户可以在网格上输入“OBSTRUCT”，以便轻松识别无法测量的位置。
Dakota FX80超声波探伤仪具有6Gb内部存储器和外部SD插槽，可通过RS232数据输出到DakMaster™数据管理软件进行高达64Gb的完整数据记录。
特征
Blanview阳光下可读QVGA TFT彩色显示屏
尺寸工具包：DAC、AWS、TCG、DGS
脉冲重复频率：8至333 Hz，可调
屏幕刷新率：60Hz
检测：Z交叉、侧面和峰值
自动：探头归零、探头识别和温度补偿
测量：多种模式可满足多种应用
大数据存储：6Gb内部和高达64Gb外部SD插槽
多种格式：字母数字网格和带自动标识符的顺序
电池寿命长达12小时
下载DakMaster™数据管理软件
美国Dakota超声波探伤仪FX80-DL/FX81-DL 参数Material Thickness Features Model FX80-DL & FX81-DL Display Mode Material thickness digits display B-Scan cross sectional display B-Scan with digits display Scan bar display Coating thickness display A-Scan display + Rectified, - Rectified, Full Waveform (RF) Flaw Detection Modes TRIG, DAC, AWS, TCG, AVG/DGS Measurement Range P-E:
Pulse Echo (Dual Contact) : 0.630 - 2,440mm (0.025 – 96”)
Pulse Echo (Single Contact) : 1.000 - 30,480mm (0.040 - 1200”)
E-E:
Echo Echo ThruPaint™ (Dual Contact): 1.270 - 102mm (0.050 - 4”)
Echo Echo (single delay line) : 0.178 - 25.4mm (0.007 - 1”)
Echo Echo (single contact) : 1.000 - 3,050mm (0.040 - 120”)
Echo Echo Verify (EEV): 1.270 - 25.4mm (0.050 - 1”)
PETP:
Pulse Echo Temp Comp: 0.630 - 2,440mm (0.025 – 96”)
CT:
Coating Thickness: 0.013 - 2.54mm (0.001 - 0.1”)
PECT:
Pulse Echo Coating Thickness (Coating) 0.010 - 2.54mm (0.001 - 0.1”)
Pulse Echo Coating Thickness (Substr.) 0.630 - 2,440mm (0.025 – 96”)Resolution 0.01mm (0.001”), 0.001mm (0.0001”) selectable Measurement Rate (Thickness Mode) Manual 4 readings per second Scan Mode 32 readings per second Scan bar display 6 readings per second High Speed Scan Mode Differential Mode Limit alarm mode B-Scan display speed adjustable display speed Calibration setups 64 user-definable setups transferrable to and from a PC archive Gates 2 (flaw) and 3 (thickness) adjustable gates: start, stop, width & threshold Damping 50, 75, 100, 300, 600, & 1500 ohms Pulser type FX80-DL: Two adjustable square wave pulsers, 100 - 200v
FX81-DL:Two tone burst pulsers, 100 - 400vGain Manual, automatic gain control (AGC) with 110dB range with 0.2dB resolution Timing Precision TCXO timing with single shot 100 MHz 8 bit ultra-low power digitizer Memory and Data Logging 4GB internal memory
Sequential and grid logging
Alpha numeric batch identification
OBSTRUCT indicates inaccessible locations
Bitmap graphic captureData Output USB-C Calibration Options single, two point, velocity, material type Transducer recognition Automatic V-path / dual path error correction Automatic Probe Zero Automatic Automatic Calibration Longitudinal (straight), or Shear (angle) Flaw Detection Product Features Probe Types Single Contact, Dual, Delay & Angle Material Velocity Table Contains longitudinal and shear velocities for a variety of material types TRIG Trigonometric display of beam path, depth, surface distance, and curved surface correction. Used with angle beam transducers DAC Up to 8 points may be entered and used to digitally draw a DAC curve. Reference -2, -6, -10, (-6/-12), (-6/-14), (-2/-6/-10) dB. Amplitude displayed in %DAC, dB, or %FSH AWS Automatic defect sizing in accordance with AWS D1.1 structural welding code. AVG/DGS Automatic defect sizing using probe data. Stores up to 64 custom setups TCG Time corrected gain. 50 dB dynamic range, 20 dB per microsecond, up to 8 points for curve definition Detection Modes Zero Crossing, Flank and Peak Display Freeze Hold current waveform on screen Peak Memory Captures peak signal amplitude PRF 8 to 2000Hz in selectable steps (8, 16, 32, 66, 125, 250, 333, 1000, 2000Hz) Skip Bar Displays skip legs in the waveform area Pulse Width 40 to 400 ns. Selectable step options 40, 80 & 400 ns (labeled spike, thin & wide) Frequency Bands FX80-DL & FX81-DL: Broadband 1.8 - 19MHz (-3dB)
FX81-DL: Six narrow bands at 0.5MHz, 1MHz, 2MHz, 5MHz, 10MHz, 15MHz.Horizontal Linearity +/- 0.4% FSW Vertical Linearity +/- 1% FSH Amplifier Linearity +/- 1 dB Amplitude Measurement 0 to 100% FSH, with 1% resolution Delay 0 - 999in (25,375mm) at steel velocity Display Blanview sunlight readable QVGA TFT colour display. 115.2 x 86.4mm (4.54 x 3.40 inches) viewable screen Display Refresh Rate 60Hz Units (selectable) mm or inches Backlight adjustable brightness Repeatability / Stability Indicator Low Battery Indicator Battery Save Mode Auto
技术参数Part Number Description Certificate Z-250-0001 Dakota FX80-DL Benchtop Flaw Detector (DFX-8) Z-251-0001 Dakota FX81-DL Benchtop Flaw Detector (DFX-8+) Operating Temperature -10 to 60ºC (14 to 140ºF) Power Supply 6 x AA batteries and via USB Battery Life2 Alkaline (12hrs), Nicad (5hrs), and NI-MH (12hrs) Gauge Weight 2.04kg (4.5lbs) - including batteries Gauge Dimensions 216.0 x 165.0 x 70.0mm (8.5 x 6.5 x 2.5 inches) Packing List Unit, Selectable Transducer, Couplant, Manual, Power Cable, Plastic Carrying Case, Certificate of Calibration and AA Batteries. PC Software and Data Transfer Cable
● 校准证书作为标准提供
-
-
