美国DAKOTA NDT螺栓应力测试仪BT2-DL/BT1-DL

美国DAKOTA NDT螺栓应力测试仪BT2-DL/BT1-DL

详细信息

品牌：美国DAKOTA NDT	型号：/BT1-DL	输入通道数：1
应力测量范围：根据自选探头	分辨率：+/-0.0001毫米	可测样品高度：根据自选探头
外形尺寸：216 x 165 x 70 mm

美国DAKOTA NDT螺栓应力测试仪BT2-DL

BT2-DL超声波螺栓张力监测器是我们螺栓产品的*新仪表。

简介
它融合了DAKOTA NDT BT1-DL螺栓张力监视器的所有伟大功能，在功能、硬件、速度和长度方面增加了一些好处。DAKOTA NDT BT2-DL超声波螺栓张力监视器非常准确地测量长度可达100英尺的紧固件，并在整体性能/功率方面得到更高提升！

当螺母和螺栓在负载下紧固在一起时，拧紧螺母的动作会增加施加在螺栓上的力，从而导致伸长。
通过使用超声波，螺栓张力监视器不受温度、摩擦或电阻因素的影响，这些因素会影响标准扭矩测量技术的精度-使达科他州BT1-DL螺栓张力监视器的精度在0.0001毫米（0.0001英寸）内。
使用仪表的USB接口以及可选的关闭附件，可以编程为在施加适当的负载时自动停止拧紧过程。

特点
显示和测量选项的范围包括：伸长率、载荷、应力和%应变、RF、校正、带限幅杆的大数字
温度补偿以对抗温度变化引起的测量不规则
数据存储能力：4GB内部内存
自动设置功能自动优化检测和调整显示
与数据端口一起工作的HI/LO警报耐受性限制

美国DAKOTA NDT螺栓应力测试仪BT2-DL特征

Model	BT2-DL
Display Mode
Material thickness digits display
A-Scan	Rectified +/- (half wave view), or RF (full waveform view)
Measurement Range	PE - 25.4 - 25,400mm (1 - 999”), EE, EEV
Resolution	+/- 0.0001mm (+/- 0.00001")
Measurement Rate
Manual	8 readings per second
Velocity Calibration Range	1250 - 13,995m/s (0.0492 - 0.5510 in/μs)
Temperature Compensation
Limit Alarm Mode
Memory and Data Logging	4GB internal memory Sequential and grid batching Bitmap graphic capture and capture viewer
Calibration Options	Automatic, fixed, single and two-point
Transducer Probe Type	Single element
Transducer Frequency Range	1 - 10MHz
Display	Blanview sunlight readable QVGA TFT color display (320 x 240 pixels) Viewable area 4.54 x 3.40 in (115.2 x 86.4 mm), or 5.7 in (144.78 mm) diagonal
Units (Selectable)	in/mm, μs
LED Backlight	On / Off/ Auto
Repeatability / Stability Indicator
Low Battery Indicator
Battery Save Mode	Auto
Transducer Connector Type	Microdot, Lemo and BNC
USB-C Interface
Temperature Sensor
Screen Refresh Rate	60Hz
Timing	Precision TCXO timing with single shot 100 MHz 8 bit ultra-low power digitizer
Pulser Type	Spike, Square Wave & Tone Burst.Pulser Voltage: 100 – 400v Selectable step options Spike, Thin, Wide, HV Spike, HV Thin, HV Wide, TB .5MHz, TB 1MHz, TB 2MHz, TB 5MHz, TB 10 MHz. Spike 40 ns, Square Wave 80 to 400 ns, Tone Burst 50 ns to 1 microsecond
Damping	50, 75, 100, 300, 600, & 1500ohms
Frequency Band	Broadband 1.8 - 19 MHz (-3dB) filter
Horizontal Linearity	+/- 0.4% FSW
Vertical Linearity	+/- 1% FSH
Amplifier Linearity	+/- 1 dB
Amplitude Measurement	0 to 100% FSH, with 1% resolution
Delay	25,400 mm (0 - 999.9”) at steel velocity
Measurement Gate	Three independent gates depending on measurement mode selected, with audible and visual alarms. Amplitude 5-95%, 1% steps
Setups	64 custom user defined setups; factory setups can also be edited by the user
Auto Set	Automates the detection, scope, and display setting process for each individual bolt
Alarm Limits	Adjustable Hi/Low tolerances with visual LED’s and audible beeper
Field Calibration	Vector or Regression correction curve for increased accuracy using Load & Stress
Alarm Limits Bar	Hi & Lo alarm limits for displaying an acceptable tolerance range
Detections	Zero Crossing
Time	Nanoseconds
Elongation	Change in length (in/mm)
Load	Force load applied (pounds KIP, or megapascals MPa)
Stress	Force for unit area stress applied (inches per inch or millimeters per millimeter)
%Strain	Ratio of elongation to effective length
Bolt Materials	Select types from a preset or custom list
Glue-On	Available for short bolts with minimal/short elongations to eliminate transducer placement errors

技术规格

Part Number	Description	Certificate
Z-197-0001	Dakota BT2-DL Benchtop Bolt Tension Monitor (Max II)
Operating Temperature	-10 to 60ºC (14 to 140ºF)
Power Supply	Lithium Ion Pack (supplied) or 6 x AA batteries
Battery Life	Lithium Pack: 18hrs, Alkaline: 12 hrs, Nicad: 5 hrs, NI-MH: 12 hrs
Gauge Weight	2.04kg (4.5lbs) - including batteries
Gauge Dimensions	216 x 165 x 70mm (8.5 x 6.5 x 2.5”)
Packing List	Unit, Lithium Pack, 4 oz. Bottle of Couplant, USB Type A to Type B Transfer Cable, Carrying Case, 10’ Lemo 00 to Microdot Transducer Cable, PC Utility Software (download from website), Operation Manual and Certification.

● 提供标准证书

标准
可追溯到NIST&MIL-STD-45662A的工厂校准
