美国达高特Dakota声波测试仪RX8-DL

美国达高特Dakota声波测试仪RX8-DL

详细信息

品牌：美国达高特	型号：RX8-DL	加工定制：否
测量范围：0.63 - 914.4 mm	测量误差：±0.5%	测量分辨率：0.01mm
数据存储：4GB	工作频率：1 - 10 MHz	外形尺寸：63.5 x 165 x 31.5 mm

美国达高特Dakota声波测试仪RX8-DL

Dakota RX8-DL声波测试仪是我们为赛车行业设计的*先进的声波测试仪。

Dakota RX8-DL声波测试仪*常用于测量气缸壁、气缸盖端口、甲板、底盘管、车身面板和挡风玻璃的厚度。Dakota RX8-DL声波测试仪的基于时间的B扫描功能在扫描圆柱体时显示横截面视图，以查看后表面的轮廓/轮廓。

美国达高特Dakota声波测试仪RX8-DL参数

Model	RX8-DL
Display Mode
Material thickness digits display
B-Scan cross sectional display
Combined B-Scan and digits display
Coating Thickness Display
Scan Bar Display
Measurement Range	PE: 0.63 - 914.4mm (0.025 - 36") EE: 2.54 - 101.6mm (0.100 - 4.0”)
Resolution	0.01mm (0.001”)
Velocity Range	305 - 18,542m/s (0.0120 - 0.7300in/μs)
Additional Features
High Speed Scan	10 - 200 readings per second
Pulser	150 volt square wave pulser
Gain	Manual or automatic gain control (AGC) with 50dB range
Timing	Precision temperature controlled crystal oscillator (TCXO) timing with single shot 100MHz 8bit ultra-low power digitizer
Memory and Data Logging	Grid (alpha numeric) Engine Map (cylinder scans)Screen Capture: Bitmap graphic capture for quick documentation (.tif ) OBSTRUCT to indicate inaccessible locations
Calibration Options
1 - point
2 - point
Material selection
Velocity (speed of sound)
Transducer Probe Type	Dual Element
Transducer Frequency Range	1 - 10MHz
V-path / dual path error correction	Automatic
Probe Zero	Manual (via integrated probe disk)
Display	12.7mm (0.5 inches) high digits
Units (selectable)	mm or inches
LED Backlight	on/off/auto
Repeatability / Stability Indicator

技术参数

Part Number	Description	Certificate
Z-158-0004	Dakota RX8-DL Sonic Tester (PR-8V)
Operating Temperature	-10 to 60ºC (14 to 140ºF)
Power Supply	3 x AA batteries and via USB
Battery Life	Alkaline – 35 hrs, Nicad – 10 hrs and NI-MH – 35 hrs
Gauge Weight	383g (13.5oz) - including batteries
Gauge Dimensions	63.5 x 165 x 31.5mm (2.5 x 6.5 x 1.24”)
Packing List	Unit, Standard Transducer, Couplant, Manual, Plastic Carrying Case and AA Batteries. PC Engine Mapping Software and Transfer Cable
