美国DAKOTA NDT高穿透测厚仪PMX4-DL

美国DAKOTA NDT高穿透测厚仪PMX4-DL

详细信息

品牌：美国DAKOTA NDT	型号：-DL	加工定制：否
测量范围：1.27 - 30500 mm	测量误差：+/- 0.01mm	测量分辨率：0.01mm
数据存储：4GB	工作频率：500kHz - 10 MHz	外形尺寸：63.5 x 165 x 31.5 mm

美国DAKOTA NDT 高穿透测厚仪PMX4-DL（HPX DL+）

Dakota PMX高穿透测厚仪专为难以穿透声音的材料而设计，这些材料由于缺乏材料一致性、颗粒结构和整体厚度而难以穿透声音。

简介

Dakota PMX高穿透精度测厚仪具有多种高压脉冲发生器选项，以及针对低频传感器（500 kHz–10 MHz）调谐的滤波器，通过在我们的应用可能性列表中添加其他材料类型，补充了我们的产品系列。常见的材料类型包括玻璃纤维、碳纤维、铸造金属、橡胶、高密度聚乙烯（HDPE）、纤维增强塑料（FRP）、铅以及所有钢和铝。

典型的目标应用是玻璃纤维板、管道、储罐、航空航天复合材料、船体、传送带、复合塑料等。有各种功能和工具可以适应多种材料类型和应用。电子平台由FPGA驱动，以提高速度和精度。25Hz的屏幕刷新率有助于仪表的整体响应性。

内置数据记录器有两种文件格式选项，网格或顺序，并配有内部4Gb SD卡作为内存。通过USB-C连接到标准PC或Apple，并与我们网站上免费下载的Windows®PC或OSX报告软件结合使用。

美国达高特DAKOTA NDT高穿透测厚仪PMX4-DL

Model	PMX4-DL
Display Mode
Material thickness digits display
B-Scan cross sectional display
Combined B-Scan and digits display
Scan bar display
A-Scan display	+ Rectified, - Rectified, Full Waveform (RF)
Measurement Range	PE contact on steel - 1.27 - 30500mm (0.05 - 1200") PE Contact on plastics - 2.54 - 127mm (0.100 - 5") EE contact on steel - 2.54 - 914.4mm (0.100 - 36") EEV contact on steel - 2.54 - 152.4mm (0.100 - 6")
Resolution	+/- 0.1mm (0.01"), +/- 0.01mm (0.001") selectable
Measurement Rate
Manual	8 readings per second
Scan Mode	250 readings per second
Scan bar display	10 to 33 readings per second
Additional Features
High Speed Scan Mode
Limit alarm mode
Selectable resolution
B-Scan display speed	10 to 200 readings per second
Calibration setups	64 custom user-definable setups, transferable to and from a PC archive
Gates	3 adjustable gates, depending on measure mode selected
Pulser Type	Spike – 200 volt, Square Wave – 400 volt, Tone Burst 400 volt, all adjustable with variable pulse widths and voltage settings
Gain	Manual or Automatic Gain Control (AGC) with 110dB range, varies with mode selected Time Dependent Gain (TDG), with variable start and slope Adjustable damping (35, 50, 75, 300, 600 & 1500ohms)
Timing	Precision TCXO timing with single shot 100 MHz 8 bit ultra-low power digitizer
Memory and Data Logging	4GB internal memory Sequential and grid logging Alpha numeric batch identification OBSTRUCT indicates inaccessible locations Bitmap graphic capture and capture viewer
Calibration Options	Single, two point, velocity and material type
Transducer Probe Type	Single element with delay tip, pencil with delay tip and contact probes
Transducer Frequency Range	500kHz - 10MHz
Transducer Recognition	manual - selectable from a list
Display	1/8” VGA (greyscale), 62 x 45.7mm (2.4 x 1.8”) viewable area
Display Refresh Rate	25Hz
Units (selectable)	mm or inches
LED Backlight	on / off / auto
Repeatability / Stability Indicator
Low Battery Indicator

电池电量低指示灯

美国达高特DAKOTA NDT高穿透测厚仪PMX4-DL技术参数

Part Number	Description	Certificate
Z-225-0002	Dakota PMX4-DL High Penetration Thickness Gauge (HPX DL+)
Operating Temperature	-10 to 60ºC (14 to 140ºF)
Power Supply	3 x AA batteries and via USB
Battery Life	Alkaline: greyscale 35 hrs Nicad: greyscale 10 hrs NI-MH: greyscale 35 hrs
Gauge Weight	383g (13.5oz) - including batteries
Gauge Dimensions	63.5 x 165 x 31.5mm (2.5 x 6.5 x 1.24”)
Packing List	Unit, custom 1” Delay Line Transducer (Rubber Delay Line) & Cable, Couplant, Manual, Certificate of Calibration, AA Batteries and Plastic Carrying Case. PC Software (download) & transfer cable included.

● 校准证书作为标准提供
