- 美国达高特DAKTA NDT精密测厚仪PMX2-DL/PMX3-DL
详细信息
品牌：美国达高特 型号：PMX2-DL/PMX3-DL 加工定制：否 测量范围：1.00 - 9144mm mm 测量误差：0.1mm+0.5% 测量分辨率：0.001mm 数据存储：4GB 工作频率：1-20 MHz 外形尺寸：63.5 x 165 x 31.5 mm 美国DAKTA NDT精密测厚仪PMX（PVX）
Dakota PMX精密测厚仪可以通过A和B扫描显示厚度值，使用户能够准确评估各种材料。
简介
Dakota PMX精密测厚仪提供0.01mm或0.001mm（0.001/0.0001“）的用户可选分辨率。
自动查找功能定位检测点并调整显示设置以显示波形。
Dakota PMX测厚仪的高速扫描功能每秒可进行250次测量，从而加快了检测过程。从测试材料上拆下传感器，并显示扫描的*小测量值。
特征
0.001mm高分辨率
显示选项范围：A扫描、B扫描、脉冲回波、回波回波
110dB范围的手动或AGC增益控制，随所选模式而变化
自动增益控制（AGC）
用户可定义的设置
多语言显示
视觉和听觉报警，具有特定应用公差的上限和下限设置。
多种校准和材料选择选项
高速扫描：每秒250个读数
差分模式
*小厚度报警
数据输出和存储：4GB内存
数据管理软件
主要特点
准确性 - 精确测量薄材料
Dakota PMX精密测厚仪灵活易用，能够以*高精度测量基板的*薄点。
强大的 - 存储每个测量值以供进一步分析
每次测量时，*多4GB的读数和波形可以保存到仪表内存中，稍后可以下载到检查应用程序或DakMaster®软件中进行进一步分析和报告。
智能化 - 用户可定义的通过/失败指示限制
可以在Dakota PMX测厚仪上为单个读数或每批设置限值，并发出声光警报。
可定制 - 选择并自定义阅读显示
通过选择显示模式，用户可以根据自己的需求选择*合适的选项；读数、选定统计数据、条形图、运行图和差分模式。
美国DAKTA NDT精密测厚仪PMX（PVX）特征Model PMX2-DL PMX3-DL Display Mode Material thickness digits display B-Scan cross sectional display Combined B-Scan and digits display Scan bar display A-Scan display + Rectified, - Rectified, Full Waveform (RF) + Rectified, - Rectified, Full Waveform (RF), Landscape View Measurement Range PE contact on steel - 1.00 - 9144mm (0.040 - 360”)
IE on steel - 1.27 - 25.4mm (0.050 - 1”)
IE on plastic - from 0.127mm (0.005”)
EE contact on steel - 2.54 - 914.4mm (0.100 - 36”)
IEE on steel - 0.152 - 12.7mm (0.006 - 0.5”)
EEV contact on steel - 2.54 - 152.4mm (0.100 - 6”)PE contact on steel - 1.00 - 9144mm (0.040 - 360”)
IE on steel - 1.27 - 25.4mm (0.050 - 1”)
IE on plastic - from 0.127mm (0.005”)
EE contact on steel - 2.54 - 914.4mm (0.100 - 36”)
IEE on steel - 0.152 - 12.7mm (0.006 - 0.5”)
EEV contact on steel - 2.54 - 152.4mm (0.100 - 6”)Resolution 0.01mm (0.001”), 0.001mm (0.0001”) selectable 0.01mm (0.001”), 0.001mm (0.0001”) selectable Measurement Rate Manual 8 readings per second 8 readings per second Scan Mode 250 readings per second 250 readings per second Scan bar display 10 to 33 readings per second 10 to 33 readings per second Additional Features High Speed Scan Mode Limit alarm mode Selectable resolution B-Scan display speed 10 to 200 readings per second 10 to 200 readings per second Calibration setups 64 custom user-definable setups, transferable to and from a PC archive 64 custom user-definable setups, transferable to and from a PC archive Gates 3 adjustable gates, depending on measure mode selected 3 adjustable gates, depending on measure mode selected Pulser Type Square wave pulser with adjustable pulse width (spike, thin, wide) Square wave pulser with adjustable pulse width (spike, thin, wide) Gain Manual or Automatic Gain Control (AGC) with 110dB range, varies with mode selected
Adjustable damping (35, 50, 75, 300, 600 & 1500ohms)Manual or Automatic Gain Control (AGC) with 110dB range, varies with mode selected
Adjustable damping (35, 50, 75, 300, 600 & 1500ohms)Timing Precision TCXO timing with single shot 100 MHz 8 bit ultra-low power digitizer Precision TCXO timing with single shot 100 MHz 8 bit ultra-low power digitizer Memory and Data Logging 4GB internal memory
Sequential and grid logging
Alpha numeric batch identification
OBSTRUCT indicates inaccessible locations
Bitmap graphic capture and capture viewer4GB internal memory
Sequential and grid logging
Alpha numeric batch identification
OBSTRUCT indicates inaccessible locations
Bitmap graphic capture and capture viewerCalibration Options Single, two point, velocity and material type Single, two point, velocity and material type Transducer Probe Type Single element with delay tip, pencil with delay tip and contact probes Single element with delay tip, pencil with delay tip and contact probes Transducer Frequency Range 1 - 25MHz 1 - 25MHz Transducer Recognition manual - selectable from a list manual - selectable from a list Display 1/8” VGA (greyscale), 62 x 45.7mm (2.4 x 1.8”) viewable area 1/4 VGA AMOLED colour display 57.6 x 43.2mm (2.27 x 1.78”) viewable area Display Refresh Rate 25Hz 25Hz Units (selectable) mm or inches mm or inches LED Backlight on / off / auto on / off / auto Repeatability / Stability Indicator
美国DAKTA NDT精密测厚仪PMX 技术规格Part Number Description Certificate Z-157-0006 Dakota PMX2-DL Precision Thickness Gauge (PVX) Z-157-0007 Dakota PMX3-DL Precision Thickness Gauge (PVX Colour) Operating Temperature -10 to 60ºC (14 to 140ºF) Power Supply 3 x AA batteries and via USB Battery Life Alkaline: greyscale 35 hrs, colour 12 hrs
Nicad: greyscale 10 hrs, colour 5 hrs
NI-MH: greyscale 35 hrs, colour 12 hrsGauge Weight 383g (13.5oz) - including batteries Gauge Dimensions 63.5 x 165 x 31.5mm (2.5 x 6.5 x 1.24”) Packing List Unit, standard 1/4" Delay Line Transducer (2 Delay Tips – 3/8” & 1/2” L) & Cable, Couplant, Manual, Certificate of Calibration, AA Batteries and Plastic Carrying Case.
● 校准证书作为标准提供。
标准
工厂校准：可追溯到NIST和MIL-STD-45662A
-
