详细信息
品牌：NewSonic 型号：SonoDur 3 加工定制：否 测量范围：10 – 1999 NV 产品类型：超声波硬度计 试验力：100 N 允许最大高度：164x86x23 mm 重量：0.37 kg
德国超声波硬度计SonoDur 3
坚固耐用 易于使用 快速准确 德国制造
满足苛刻的应用要求，可在野外和生产现场的恶劣条件下正常工作可更换的锂电池，提高设备的续航能力高亮度TFT 彩色触摸屏，保证在阳光直射下，轻松读取所有信息优良的固件设计和易于使用的操作系统人性化的程序设计导航性的操作菜单，简单易懂触摸屏和发光键盘，使得能在黑暗环境下操作自如大容量的数据存储能力屏幕直接增加趋势图，用起来更直接了。
可以配个座充，插在上面，更加简易随手。
SonoDur2之后的新UCI硬度测试方法。
SonoDur3更好的硬度测试方法。
超声波接触阻抗
规范：ASTM A 1038和DIN 50159-1,2
转换：ASTM E 140-13，EN ISO 18265
仪器功能
•背带，边缘保护，IP65，MIL-810G（振动，冲击，跌落）
•5英寸亮色显示屏，光滑玻璃屏蔽，便于清洁
•直接功能访问，只需通过触摸，直观的菜单控制，非常适合MIC10 / MIC20用户和其他人
•班次开始时无需设置 - 可立即使用Android操作系统和数据传输
•USB：使用.txt格式传输测量数据文件管理器
•WLAN：自动传输单个值，完成数据步骤
•蓝牙：手动传输一组测量数据
•测量数据和设置的“无限”存储容量智能管理测量数据和设置
•简单的数据访问和合格的可追溯评估结果
•可以预定义文件名，自动关闭数据集
•“AllMeas” - 存储的结果汇总列表数据集
可靠的测量
具有长期稳定性的技术高效的工作工具，优化了检查员的日常需求*可以*按照校准DIN 50159-2后的DAKKS（校准曲线150 - 至900 HV试验力）
德国超声波硬度计
NewSonic SonoDur 3
The New UCI Generation after SonoDur2
Mobile Hardness testing onmetals with UCI * in productionand maintenance. Starting withgoods income inspection untilthe fi nal product is reached.
*Ultrasonic Contact Impedance
Norms: ASTM A 1038 and DIN 50159-1, 2
Conversions: ASTM E 140-13, EN ISO 18265
Multiple Solutions for theSonoDur Family and also forMIC10/MIC20 (by probe retrofi t)
Motor probes (HV 0,1 – HV 0,8): 0.1 kgf, 0.3 kgf, 0.8 kgf
Handheld probes (HV 1 – HV 10): 1 kgf, 3kgf, 5 kgf, 10 kgf
The better Way to Hardness Testing
Rugged, easy to use, fast and precise. Made in Germany.
Instrument Features
• Carrying strap, edge protection, IP65, MIL-810G (vibration, shock, drop)
• Brilliant color display in 5’’, smooth glass shield for easy cleaning
• Direct function access just by touch, intuitive menu control, ideal forMIC10/MIC20 users and others
• No set-up needed at beginning of shift – ready for immediate useAndroid Operating System and Data Transfer
• USB: transfer of measurement data in txt-format using thefile explorer
• WLAN: automatic transfer of single values, completed data stets
• Bluetooth: manual transfer of a set of measurement data
•“Unlimited”storage capacity for measurement data and settings
Intelligent Management ofMeasurement Data and Settings
• Simple access to data and qualified back-traceableassessment of results
• File names can be predefined, automatic closingof data sets
•“AllMeas”- summarized list of results in storeddata sets
Reliable MeasurementTechnique with long-Term Stability
Efficient working tool, optimized for the
daily needs of the inspector
Unique
Can be calibrated in full according to
DAKKS after DIN 50159-2 (calibration
curve 150 – through 900 HV, diamond,
nominal test force)
NewSonic SonoDur 3
Measuring Specifications
* exceeds DIN 50159, dependent on test load and range (see table below). Specifications are valid for 5 measurements usingVickers reference blocks and according to test conditions given in standard DIN 50159.Measuring principle UCI Method, corresponds to DIN 50159, ASTM A1038 Test indenter Vickers diamond 136° Test loads
Newton scale (1kgf = 9.81 N)Motor probes: 1N (0.1 kgf), 3N (0.3kgf) and 8.6 N (0.9 kgf)
Handheld Probes: 10N (1 kgf), 30N (3kgf), 49N (5kgf), 98N(10kgf), (Other test loads on request)Hardness scales and range
(according to relevant standards), in this casetable A1 respectively T1, T2 (low alloy steel).
Different measuring ranges are valid for othermaterials. When exceeding the limits theconversion range will be extended. The calcu-lated values are highlighted in red besides theoriginal data in HV.
Note:
Conversions are acc. to latest ASTM
E140-12bԐ1(2013) und EN ISO 18265:2014.
Conversions into tensile strength: 98N (10kgf)test load only.Vickers
Brinell
Rockwell
Rockwell
Rockwell
Rockwell
Rockwell 5,6
Rockwell (EN ISO 18265 only)
Rockwell
Knoop (ASTM E140 only)
Shore (ASTM E140 only)
Tensile strengthHV
HB
HRB
HRC
HRE
HRF
HRA
HRD
HR45N
HK
HS
MPa10 – 1999 (9999)
76 – 618
41 – 105
20,3 – 68
70 – 108,5
82,6 – 115,1
60,7 – 8
40,3 – 76,9
19,9 – 75,4
87 – 920
34,2 – 97,3
255 – 2180Measurement uncertainty* < 4 % (HV5, HV 10). For other test loads and ranges see table below. Relative repeatability* < 5 % (HV5, HV 10). For other test loads and ranges see table below.
Hardness
scaleMeasurement uncertainty [%] Relative repeatability [%] < 250 HV 250 HV - 500HV 500 HV - 800 HV > 800 HV < 250 HV > 250 HV HV 0,1 5 6 7 8 8 6 HV 0,3 5 6 7 8 8 6 HV 0,8 4 4 5 6 8 6 HV 1 4 4 5 6 8 6
Mechanical and Environmental (Instrument and probe)
Operating time >10 hours in measurement operation (depending on system performance,temperature and instrument settings), up to 8 hours continuous operation, quick exchangeable battery pack (3.7V 3900mAh LiPolymer) Operating Temperature Probe: 0°C to ~ +45°C
Instrument: -10° ~ +50°C // Charging +10°C ~ +40°CStorage Temperature -20°C ~ +70°C Humidity Max. 90%, non-condensing Dimensions Instrument ca. 164x86x23 mm, Motor probe Ø38mm, L=190 mm
Handheld probe Ø25 mm, L=176 mm (free length of rod ca. 12,5 mm)
Handheld probe Ø25 mm, L=207 mm (free length rod ca. 43 mm)Weight Instrument ca. 320 gr (incl. battery pack)
Handheld probe ca. 280 gr, Motor probe ca. 370 gr
Instrument
Processor and Memory ARM ® Cortex™-A53 Octa Core 1.3 GHz / System 2GB RAM /
storage me mory 16 GB eMMC / Micro SD card 4 GB (up to 32 GB )Operating system Android 5.1 (Android 7.0) Keypad 4 function keys, system touch keyboard Power Main battery: 3,7V / 3900mAh, LiPo hard pack, quick exchange
Charging time: <3h to 80% capacity (Instrument off)
Shelf Hours: Up to 6 months
AC Power supply/charger: 90V to 264VAC 50/60Hz to 5VDCDisplay 5“ sunlight readable multi touch display (1280x720 pixel),
LED-backlight (500 Cd/m2), adjustableInterfaces Jack for 5VDC operating/ charging |Docking connector (charging)
USB 2.0 Micro USB (PC) / probe connector Lemo 4 pos.
Micro SD-card 4 GB (up to 32 GB) | 2x SIM card
WLAN 802.11 a/b/g/n | WCDMA/HSDAP/HSPUA, FDD-LTE / TDD-LTE) |
GSM/GPRS/EDGE (b2/b3/b5/b8 | GPS / AGPS / GLONASS
Bluetooth 4.0 (supports BLE mode) | NFC | Speaker, microphoneSensors / Camera / LED Light sensor, G-sensor, proximity sensor, rear camera 8 mega-pixel,
multicolor status LEDIP-Proof IP65 according IEC 60529 Edition 2.1:2001-02 Drop test MIL-STD-810G Methode 516.6, 4 ft. Shock Test MIL-STD-810G Methode 516.6 Prozedur I Vibration Test MIL-STD-810G Methode 514.6 Prozedur I Instrument Language D, EN, IT, FR, SP, PL, CZ, CN - more on request
NewSonic SonoDur 3
Scope of delivery
SonoDur3, Hardness Tester with Data Logger and Data Export, Data Transfer to PC (USB, WLANor Bluetooth resp.), incl. SONO3-NG, Power Source, SONO2-NG/USB USB-Cable, SONO2-HM, ca. 1,5 mProbe Connection Cable, SONO3-TK-1, Transportation Case, SONO-CD, Product-USB-Stick, SONO3Protect, Protection Foils
Mandatory accessory
Motor probe or handheld probe respectively
Other accessories
Reference blocks (MPA, company certificate),test stands, guiding harnesses, auxiliary SW.
Example for configurations
-
-
