- 美国DAKOTA超声波测厚仪CX系列2-4-6-8
详细信息
品牌:美国DAKOTA 型号:2-4-6-8 加工定制:否 测量范围:0.63 - 500 mm 测量误差:±0.5% 测量分辨率:0.01mm 数据存储:1000000 工作频率:4-16 MHz 外形尺寸:145 x 73 x 37 mm
Dakota CX超声波材料测厚仪具有测量几乎任何材料的材料厚度和速度所需的所有特性和功能,适用于广泛的应用。
智能化
用户可定义的通过/失败指示限制
用户可以通过声音和视觉通过/失败警告设置上限和下限。可以为单个读数或每批读数设置限制。
准确
一系列精度和效率校准选项
Dakota CX测厚仪有一系列校准选项,包括1点校准方法。用户还可以选择存储在仪表内的39种预设材料中的一种,或将*多三次校准存储到存储器中。
多功能
测量未涂层和涂层表面
Dakota腐蚀计系列灵活易用,不仅可以测量未涂层表面,还可以测量涂层表面。使用Echo Echo ThruPaint™模式(EE)时,*大2mm(80mils)的涂层将被忽略。
Dakota CX 测厚仪
自动识别,确保在更换传感器时识别正确的探头
16Hz的扫描模式,非常适合测量大表面积
用户可选择的阅读分辨率;0.1毫米(0.01英寸)或0.01毫米(0.001英寸)
脉冲回波(PE)、回波回波ThruPaint™和速度(VM)测量模式
高低限指示器指示问题区域
集成零盘,确保*高精度
在多达1000个连续批次中存储多达100000个读数
可选择4、8、16Hz的读取速率(每秒4、8和16个读数)
Dakota CX测厚仪
无线连接
连接到PC
与DakMaster™PC兼容,可通过USB下载读数以进行进一步分析和报告。
可定制
选择并自定义阅读显示
Dakota CX测厚仪系列有多种显示模式可供选择,允许用户选择*适合他们需求的显示模式;读数、选定统计数据、条形图、运行图、B扫描和差分模式。
产品特点Features Model Model Number CX2 CX4 CX6-DL CX8-DL Easy to use menu structure in multiple languages Tough, impact, waterproof and dust resistant equivalent to IP64 Bright colour screen; with permanent backlight Ambient light sensor, with adjustable brightness Scratch and solvent resistant display; 2.4" (6cm) TFT Large positive feedback buttons USB power supply; via PC Gauge software updates via DakMaster™ Software 2 year gauge warranty2 Limits: 40 definable audible & visual pass/fail warnings Measurement Mode Pulse Echo (PE) Echo Echo ThruPaint™ (EE) Velocity Mode (VM) Measurement Rate 4, 8, 16Hz 4Hz 4, 8, 16Hz3 4, 8, 16Hz3 Thickness Range 4 PE 0.63-500mm (0.025-19.999") EE 2.54 - 25.4mm (0.100-1.0”) Measurement Units mm or inches m/s, inch/μs Repeatability / Stability Indicator Display Mode Reading Selected statistics Scan thickness bar graph Run Chart Readings and Differential B-Scan cross sectional display Selectable Reading Resolution Lo; 0.1mm, 0.01 Inch, 10m/s, or 0.001 in/μs Hi; 0.01mm, 0.001 Inch, 1m/s, or 0.0001 in/μs Statistics Number of readings,n; Mean average, x ; Standard deviation, σ. Lowest reading, Lo; Highest reading, Hi Low / high limit value Reading Range Value Nominal Value Number of readings below the low limit Number of readings above the high limit Calibration Options Zero (using the integral zero disc) 1 - point 2 - point Material selection; 39 preset materials Factory; resets to the factory calibration Velocity (speed of sound) Known thickness value Calibration Features Calibration lock; with optional PIN Lock Test calibration feature Calibration memories: 3 programmable memories Measurement outside calibration warning Data Logging Number of readings 1,500 100,000 Number of batches 1 1,000 Sequential batching Grid batching Fixed Batch Size Mode; with batch linking Obstruct entry; add 'obst' into grid location Delete last reading Date & time stamp Review, clear & delete batches Alpha numeric batch names; user definable Batch review graph Data Output USB to PC Bluetooth® to PC, Android™ & iOS devices DakMaster™ software Transducer Probe Type Dual Element Auto transducer recognition Auto V-path correction
技术规范
Part Number Description Certificate CX2 Dakota CX2 Material Thickness Gauge CX4 Dakota CX4 Material Thickness Gauge CX6-DL Dakota CX6-DL Material Thickness Gauge CX8-DL Dakota CX8-DL Material Thickness Gauge Model Number CX2 CX4 CX6-DL CX8-DL Measurement Range1 Pulse Echo (PE) 0.63 - 500mm (0.025 - 19.999”) 0.63 - 500mm (0.025 - 19.999”) 0.63 - 500mm (0.025 - 19.999”) 0.63 - 500mm (0.025 - 19.999”) Echo Echo ThruPaint™ (EE) 2.54 - 20.00mm (0.100-0.787”) 2.54 - 20.00mm (0.100-0.787”) 2.54 - 20.00mm (0.100-0.787”) Velocity Mode (VM) 1,250-10,000m/s (0.0492 - 0.3937in/μs) 1,250-10,000m/s (0.0492 - 0.3937in/μs) 1,250-10,000m/s (0.0492 - 0.3937in/μs) Measurement Accuracy2 Pulse Echo (PE) ±0.1mm (0.63-19.99mm)
±0.5% (20.00-500.00mm)±0.1mm (0.63-19.99mm)
±0.5% (20.00-500.00mm)±0.05mm (0.63-9.99mm)
±0.5% (10.00-500.00mm)
±0.004” (0.025-0.393”)
±0.5% (0.394-20.00”)±0.05mm (0.63-9.99mm)
±0.5% (10.00-500.00mm)
±0.004” (0.025-0.393”)
±0.5% (0.394-20.00”)Echo Echo ThruPaint™ (EE) ±0.1mm (2.54-25.4mm) ±0.1mm (2.54-25.4mm) ±0.05mm (2.54-9.99mm)
±0.5% (10.00-20.00mm)
±0.004” (0.100-0.393”)
±0.5% (0.394-0.787”)±0.05mm (2.54-9.99mm)
±0.5% (10.00-20.00mm)
±0.004” (0.100-0.393”)
±0.5% (0.394-0.787”)Operating Temperature -10 to 50°C (14 to 122°F) Power Supply 2 x AA batteries Battery Life3 Alkaline: 15 hours Lithium: 28 hours Gauge Weight 210g (7.4oz) - including batteries, without transducer Gauge Dimensions 145 x 73 x 37mm (5.7 x 2.84 x 1.46”), without transducer Packing List Dakota CX2 Ultrasonic Material Thickness Gauge, 5MHz ¼” right angle dual element transducer (TXC5M00CP-4), ultrasonic couplant, carry pouch, screen protector, wrist harness, 2 x AA batteries, operating instructions, test certificate
Dakota CX4 Ultrasonic Material Thickness Gauge, 5MHz ¼” HD right angle dual element transducer (TXC5M00CP-10), ultrasonic couplant, carry pouch, screen protector, wrist harness, 2 x AA batteries, operating instructions, test certificate
Dakota CX6-DL Ultrasonic Material Thickness Gauge, 5MHz ¼” HD right angle dual element transducer (TXC5M00CP-10), ultrasonic couplant, plastic transit case, 3 x screen protectors, wrist harness, 2 x AA batteries, operating instructions, calibration certificate, DakMaster® software CD & USB cable
Dakota CX8-DL Ultrasonic Material Thickness Gauge, 5MHz ¼” HD right angle dual element transducer (TXC5M00CP-10), ultrasonic couplant, plastic transit case, 3 x screen protectors, wrist harness, 2 x AA batteries, operating instructions, calibration certificate, DakMaster® software CD & USB cable
校准证书作为标准提供
1取决于被测材料和使用的传感器。
2标准块。
3在读取速率为4Hz的连续读取模式下,电池的大致寿命。可充电电池可能有所不同。
